File:SGI Origin 2000 deskside rear.png
Size of this preview: 573 × 600 pixels. Other resolution: 1,067 × 1,117 pixels.
Original file (1,067 × 1,117 pixels, file size: 80 KB, MIME type: image/png)
Summary
[edit | edit source]
Line drawing of the back of the Origin 2000 deskside chassis: node board slots 1 to 4, BaseIO panel, AC input and main power switch.
Source
[edit | edit source]
Rendered from SGI, Origin2000 Deskside Owner's Guide, 007-3453-002, p. 16, Figure 2-5 (File:SGI Origin2000 Deskside Owner's Guide (007-3453-002).pdf), 2026-10-21.
Author
[edit | edit source]
Silicon Graphics, Inc.
Licence
[edit | edit source]
Copyright Silicon Graphics, Inc. Hosted for preservation and repair reference, with the source cited.
