File:SGI Origin 200 fan locations.png
Size of this preview: 721 × 600 pixels. Other resolution: 914 × 760 pixels.
Original file (914 × 760 pixels, file size: 85 KB, MIME type: image/png)
Summary
[edit | edit source]
Line drawing of an open Origin 200 chassis showing the three cooling fans behind the drive bays, numbered fan 1 (behind the 5.25-inch bay) to fan 3 (nearest the PCI backplane).
Source
[edit | edit source]
Rendered from SGI, Origin200 Owner's Guide, 007-3415-003, p. 23, Figure 1-11 (File:SGI Origin200 Owner's Guide (007-3415-003).pdf), 2026-10-21.
Author
[edit | edit source]
Silicon Graphics, Inc.
Licence
[edit | edit source]
Copyright Silicon Graphics, Inc. Hosted for preservation and repair reference, with the source cited.
