File:SGI Origin 200 front panel controls.png
Size of this preview: 800 × 388 pixels. Other resolution: 885 × 429 pixels.
Original file (885 × 429 pixels, file size: 25 KB, MIME type: image/png)
Summary
[edit | edit source]
Line drawing of the Origin 200 front panel: status LED, front power switch, nonmaskable interrupt (NMI) button and reset button.
Source
[edit | edit source]
Rendered from SGI, Origin200 Owner's Guide, 007-3415-003, p. 76, Figure 4-1 (File:SGI Origin200 Owner's Guide (007-3415-003).pdf), 2026-10-21.
Author
[edit | edit source]
Silicon Graphics, Inc.
Licence
[edit | edit source]
Copyright Silicon Graphics, Inc. Hosted for preservation and repair reference, with the source cited.
