File:SGI Origin 3000 series tall and short racks.png
Size of this preview: 472 × 600 pixels. Other resolution: 972 × 1,235 pixels.
Original file (972 × 1,235 pixels, file size: 242 KB, MIME type: image/png)
Summary
[edit | edit source]
Drawing of the Origin 3000 series tall (39U) and short (17U) racks.
Source
[edit | edit source]
Rendered from SGI, SGI Origin 3000 Series Owner's Guide, 007-4240-002, p. 2, Figure 1-1 (File:SGI Origin 3000 Series Owner's Guide (007-4240-002).pdf), 2026-10-22.
Author
[edit | edit source]
Silicon Graphics, Inc.
Licence
[edit | edit source]
Copyright Silicon Graphics, Inc. Hosted for preservation and repair reference, with the source cited.
