File:SGI Origin 300 front panel controls.png
Size of this preview: 800 × 367 pixels. Other resolution: 1,133 × 520 pixels.
Original file (1,133 × 520 pixels, file size: 105 KB, MIME type: image/png)
Summary
[edit | edit source]
Drawing of the Origin 300 front panel: L1 controller display, service-required and failure LEDs, power button with LED, NMI and reset buttons, and drive LEDs.
Source
[edit | edit source]
Rendered from SGI, SGI Origin 300 User's Guide, 007-4365-002, p. 6, Figure 1-3 (File:SGI Origin 300 User's Guide (007-4365-002).pdf), 2026-10-22.
Author
[edit | edit source]
Silicon Graphics, Inc.
Licence
[edit | edit source]
Copyright Silicon Graphics, Inc. Hosted for preservation and repair reference, with the source cited.
