File:SGI Origin 300 internal components.png
Size of this preview: 800 × 320 pixels. Other resolution: 1,234 × 493 pixels.
Original file (1,234 × 493 pixels, file size: 214 KB, MIME type: image/png)
Summary
[edit | edit source]
Drawing of the inside of an Origin 300 base module: DIMMs, IP45 motherboard, fans, SCSI backplane, internal disk drives, L1 display, power supply, power supply fan and I/O-8 assembly.
Source
[edit | edit source]
Rendered from SGI, SGI Origin 300 System with NUMAlink Module User's Guide, 007-4498-002, p. 124, Figure A-6 (File:SGI Origin 300 System with NUMAlink Module User's Guide (007-4498-002).pdf), 2026-10-22.
Author
[edit | edit source]
Silicon Graphics, Inc.
Licence
[edit | edit source]
Copyright Silicon Graphics, Inc. Hosted for preservation and repair reference, with the source cited.
