File:SGI Origin 350 power supply location.png
Size of this preview: 800 × 404 pixels. Other resolution: 1,197 × 605 pixels.
Original file (1,197 × 605 pixels, file size: 125 KB, MIME type: image/png)
Summary
[edit | edit source]
Drawing of the Origin 350 compute module with the right-hand bezel door open, showing the two sled-mounted power supplies behind it.
Source
[edit | edit source]
Rendered from SGI, SGI Origin 350 Server System User's Guide, 007-4566-001, p. 181, Figure 6-21 (File:SGI Origin 350 Server System User's Guide (007-4566-001).pdf), 2026-10-22.
Author
[edit | edit source]
Silicon Graphics, Inc.
Licence
[edit | edit source]
Copyright Silicon Graphics, Inc. Hosted for preservation and repair reference, with the source cited.
