File:SGI Origin 350 rear panel.png
Size of this preview: 800 × 265 pixels. Other resolution: 1,412 × 467 pixels.
Original file (1,412 × 467 pixels, file size: 125 KB, MIME type: image/png)
Summary
[edit | edit source]
Drawing of the Origin 350 compute module rear panel: power connector, console port, serial ports, L1 USB port, PS/2 ports, XIO and NUMAlink connectors, four PCI/PCI-X slots with the IO9 card in the lowest, RTI/RTO, Ethernet and external SCSI connectors.
Source
[edit | edit source]
Rendered from SGI, SGI Origin 350 Server System User's Guide, 007-4566-001, p. 124, Figure 3-6 (File:SGI Origin 350 Server System User's Guide (007-4566-001).pdf), 2026-10-22.
Author
[edit | edit source]
Silicon Graphics, Inc.
Licence
[edit | edit source]
Copyright Silicon Graphics, Inc. Hosted for preservation and repair reference, with the source cited.
