Crop of the underside of a North American SNS-CPU-APU-01 Super NES main board near the power input: the regulator's three joints marked I, G and O with the surface-mount capacitor C61 beside them; a chip link R28 marked [SNS/SNSM]; capacitors C32 to C34; the power-switch connector pads 1 and 2; and the axial fuse, visible past the board edge, marked SOC 1.5A.
Source
[edit | edit source].jpg&veaction=edit§ion=2){kind=link}
.jpg&action=edit§ion=2){kind=link}
Cropped from Nintendo-Super-NES-Mk1-Motherboard-Bottom.jpg on Wikimedia Commons (retrieved 2026-10-25).
Author
[edit | edit source].jpg&veaction=edit§ion=3){kind=link}
.jpg&action=edit§ion=3){kind=link}
Evan-Amos.
Licence
[edit | edit source].jpg&veaction=edit§ion=4){kind=link}
.jpg&action=edit§ion=4){kind=link}
Public domain, as released by the author on Wikimedia Commons.
