The two boards of a Genesis 32X, top side. The larger board is what Sega's service manual calls the sub board, with the 32X's own cartridge slot, the AV and DC connectors and the power supply. The smaller board below it is the main board, with the two SH2 processors, the VDP and the edge connector that plugs into the console. The two are joined by the 40-pin flat cables.
Source
[edit | edit source]
https://commons.wikimedia.org/wiki/File:Sega-Genesis-32X-Motherboard-Top.jpg (retrieved 2026-10-01). Downscaled for this wiki.
Author
[edit | edit source]
Evan-Amos
Licence
[edit | edit source]
Public domain. The author released this photograph into the public domain on Wikimedia Commons.
