Summary

"MZ-3541 System Configuration" diagram from a Sharp English-language brochure: what is built into the MZ-3541 (two Z80A CPUs, 128 KB RAM, 8 KB CG and IPL ROMs, 3 KB video RAM, MFD, printer, RS-232C, keyboard, light pen and two CRT interfaces) and the options (MZ-1U02 expansion unit, MZ-1R06 and MZ-1R07 RAM, MZ-1E01 RS-232C, MZ-1R03 graphic board, MZ-1R04 graphic RAM, MZ-1F02 drives, MZ-1D07 and MZ-1D08 displays, MZ-1P02 printer, MZ-1K03 keyboard). Cropped from the top of the brochure page.

Source

SharpMZ.net, MZ-3500 adverts page: https://www.sharpmz.net/mz-3500/adverts.htm (image https://www.sharpmz.net/mz-3500/images/mz3541ade1_1.jpg, retrieved 2026-10-21). Cropped.

Author

Sharp (brochure).

Licence

Copyright Sharp. Used to identify the product.
