File:Sinclair QL Issue 6 layout, RAM and keyboard connectors.png
Size of this preview: 800 × 309 pixels. Other resolution: 2,000 × 773 pixels.
Original file (2,000 × 773 pixels, file size: 163 KB, MIME type: image/png)
Summary
[edit | edit source]
Part of Sinclair's Issue 6 component layout for the Sinclair QL main board: the sixteen RAM chips IC1 to IC16, the 68008 (IC18) and ZX8301 (IC22) at the left, and the keyboard connectors J11 and J12 with their pin 1 marked.
Source
[edit | edit source]
Cropped from File:Sinclair QL PCB component layout (Issue 6).png, Sinclair's Issue 6 component layout (QL Service Manual, Figure 5.2, page 5.12).
.png){kind=link}
Author
[edit | edit source]
Sinclair Research Ltd
Licence
[edit | edit source]
Copyright Sinclair Research Ltd. Reproduced from the service manual for repair reference; not freely licensed.
