File:Sinclair QL motherboard.jpg
Size of this preview: 800 × 326 pixels. Other resolution: 2,600 × 1,058 pixels.
Original file (2,600 × 1,058 pixels, file size: 508 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
Sinclair QL with the top case removed: the main board, the ribbon cables to the keyboard, the large black heatsink and the two Microdrive mechanisms at the right. Downscaled from the 3277-pixel Commons original.
Source
[edit | edit source]
Wikimedia Commons, File:QL-inside.jpeg (13 May 2007).
Author
[edit | edit source]
Ewx
Licence
[edit | edit source]
