File:Sinclair ZX81 circuit diagram.png
Size of this preview: 677 × 600 pixels. Other resolutions: 2,312 × 2,048 pixels | 3,396 × 3,008 pixels.
Original file (3,396 × 3,008 pixels, file size: 620 KB, MIME type: image/png)
Summary
[edit | edit source]
Sinclair's ZX81 circuit diagram, drawing number SRC 049, at 3396 × 3008 pixels. The scan carries the note "scanned by http://www.8bit.ht.st/".
Source
[edit | edit source]
PNG copy, at the same pixel size, of "ZX81 Circuit Diagram.gif" in the Sinclair ZX Computers Archive, https://k1.spdns.de/Vintage/Sinclair/80/Sinclair%20ZX81/Service%20and%20Assembly%20Manual/ (checked 2026-10-01).
Author
[edit | edit source]
Sinclair Research Ltd
Licence
[edit | edit source]
Copyright Sinclair Research Ltd. Not freely licensed. Hosted for preservation and repair reference.
File history
Click on a date/time to view the file as it appeared at that time.
| Date/Time | Thumbnail | Dimensions | User | Comment | |
|---|---|---|---|---|---|
| current | 17:26, 22 September 2026 | | 3,396 × 3,008 (620 KB) | Josh (talk | contribs) | Full-resolution Sinclair ZX81 circuit diagram (SRC 049) |
