Section 10.5 of Sinclair's ZX Spectrum Service Manual, "Spectrum+ Keyboard – Top Membrane": the key matrix of the top membrane, with the 8-way tail (KB2) connected through diodes D1 to D8 to address lines A8 to A15, and the 5-way tail (KB1) to the ULA's inputs KB0 to KB4 with pull-up resistors R65 to R69. Used on Sinclair ZX Spectrum+ Keyboard Membrane Replacement.
Source
[edit | edit source].png&veaction=edit§ion=2){kind=link}
.png&action=edit§ion=2){kind=link}
File:Sinclair ZX Spectrum Service Manual.pdf (re-typeset Revision 1.3, Spectrum For Everyone), page 59; the drawing is the scanned image embedded in that page, extracted at its native resolution.
Author
[edit | edit source].png&veaction=edit§ion=3){kind=link}
.png&action=edit§ion=3){kind=link}
Sinclair Research Ltd
Licence
[edit | edit source].png&veaction=edit§ion=4){kind=link}
.png&action=edit§ion=4){kind=link}
Copyright Sinclair Research Ltd. Not freely licensed. Hosted for preservation and repair reference.
