File:Sinclair ZX Spectrum Issue 1 colour presets and trimmers.jpg
Summary
[edit | edit source]
Crop of a photograph of a Sinclair ZX Spectrum Issue 1 main board (ULA 5C112E) showing the colour circuit: the LM1889N colour encoder (IC14), the 4.433619 MHz and 14.000 MHz ITC crystals, two trimmer capacitors beside the crystals, two 2.2 kΩ skeleton presets below them, and the 5-way keyboard connector at the top. Cropped for Sinclair ZX Spectrum Colour Adjustment.
Source
[edit | edit source]
Cropped from File:Sinclair ZX Spectrum Issue 1 Motherboard.jpg on Wikimedia Commons (retrieved 2026-10-25), originally published on Flickr by AUIC Oficial on 29 April 2018 (RetroMadrid 2018).
Author
[edit | edit source]
AUIC Oficial, photograph by Fernando Sáenz
Licence
[edit | edit source]
Public domain: marked by the author with the Public Domain Mark on Flickr and recorded on Commons as Template:PD-author-FlickrPDM.
