File:Sinclair ZX Spectrum Issue 3 DC-DC converter circuit.png
Summary
[edit | edit source]
Crop of Sinclair's ZX Spectrum Issue 3 circuit diagram showing the DC-DC converter (TR4, TR5, the coil, D15, C44, C45, the −5 V rail through C46, D11, R55, D16 and D12, and the −12 V output) with the 7805 output capacitor C34 and the box listing the Issue 3B changes. Cropped at full resolution for Sinclair ZX Spectrum DC-DC Converter Repair.
Source
[edit | edit source]
Cropped from File:Sinclair ZX Spectrum Issue 3 circuit diagram.png, itself a copy of "ZX Spectrum Issue 3 - Schaltbild.gif" in the Sinclair ZX Computers Archive.
Author
[edit | edit source]
Sinclair Research Ltd
Licence
[edit | edit source]
Copyright Sinclair Research Ltd. Not freely licensed. Hosted for preservation and repair reference.
