File:Sinclair ZX Spectrum Issue 4B 7805 regulator and power socket.jpg
Summary
[edit | edit source]
Close crop of a Sinclair ZX Spectrum Issue 4B main board showing the 7805 regulator (a National Semiconductor LM340T5, date code 8424) bolted by a slotted screw to the heatsink, next to the 2.1 mm power socket at the top right of the board. Cropped for Sinclair ZX Spectrum Voltage Regulator Replacement.
Source
[edit | edit source]
Cropped from File:Sinclair ZX Spectrum Issue 4B Motherboard.jpg on Wikimedia Commons (retrieved 2026-10-25), originally published on Flickr by AUIC Oficial on 29 April 2018 (RetroMadrid 2018).
Author
[edit | edit source]
AUIC Oficial, photograph by Fernando Sáenz
Licence
[edit | edit source]
Public domain: marked by the author with the Public Domain Mark on Flickr and recorded on Commons as Template:PD-author-FlickrPDM.
