File:Sinclair ZX Spectrum Issue 4B TR4 and TR5.jpg
Size of this preview: 472 × 236 pixels.
Original file (472 × 236 pixels, file size: 21 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
Close crop of a Sinclair ZX Spectrum Issue 4B main board showing TR4 and TR5 (silkscreen TR4 and TR5), D15 below TR4, and the H and N ROM selection links at the lower right. Cropped for Sinclair ZX Spectrum DC-DC Converter Repair.
Source
[edit | edit source]
Cropped from File:Sinclair ZX Spectrum Issue 4B Motherboard.jpg on Wikimedia Commons (retrieved 2026-10-25), originally published on Flickr by AUIC Oficial on 29 April 2018 (RetroMadrid 2018).
Author
[edit | edit source]
AUIC Oficial, photograph by Fernando Sáenz
Licence
[edit | edit source]
Public domain: marked by the author with the Public Domain Mark on Flickr and recorded on Commons as Template:PD-author-FlickrPDM.
