File:SparkFun green wire repair of a cut trace to a via.jpg
Summary
[edit | edit source]
The corner of a red SparkFun shield board, seen from the component side. A trace from the TX solder-jumper pad was cut by accident while another trace was being cut; it has been repaired with a short piece of green insulated wire soldered from the jumper pad to a via on the same net, with the via's solder mask scraped off.
Source
[edit | edit source]
SparkFun Electronics, "How to Work with Jumper Pads and PCB Traces", section "Rerouting and Green Wire Repair", image PCBRepairGreenWireFix.jpg (retrieved 2026-10-25). Full-size file.
Author
[edit | edit source]
SparkFun Electronics; tutorial contributor bboyho. The tutorial says the repair was made on Nate's Electric Imp shield.
Licence
[edit | edit source]
SparkFun tutorials are published under the Creative Commons Attribution-ShareAlike 4.0 licence, as stated on the tutorial page.
