A 330 µF 10 V surface-mount aluminium electrolytic capacitor (C142) with the dark segment on its top marking the negative side, next to an unpopulated footprint (C165) whose silkscreen marks the positive pad with a + sign. Copied from Wikimedia Commons, where the file is titled Smd radial.
Source
[edit | edit source].jpg&veaction=edit§ion=2){kind=link}
.jpg&action=edit§ion=2){kind=link}
Wikimedia Commons, File:Smd radial.jpg (retrieved 2026-10-25).
Author
[edit | edit source].jpg&veaction=edit§ion=3){kind=link}
.jpg&action=edit§ion=3){kind=link}
WizardTim (Wikimedia Commons user)
Licence
[edit | edit source].jpg&veaction=edit§ion=4){kind=link}
.jpg&action=edit§ion=4){kind=link}
CC BY 4.0, as stated on Wikimedia Commons.
