File:VIC20 Schematic.png
Size of this preview: 800 × 541 pixels. Other resolution: 1,200 × 812 pixels.
Original file (1,200 × 812 pixels, file size: 251 KB, MIME type: image/png)
Summary
[edit | edit source]
The memory section of a Commodore VIC-20 schematic, redrawn: the 2114 and M58725P RAMs, the ROMs, the 4066 switch and the 74LS138 address decoder. It carries the address http://www.cbmhardware.de.
Source
[edit | edit source]
Not recorded. The image carries the address of cbmhardware.de.
Author
[edit | edit source]
Not recorded.
Licence
[edit | edit source]
Not recorded.
