Summary
[edit | edit source]
Underside of the Sanyo MPC-200 main board, showing the surface-mounted Toshiba T7775 MSX-Engine (marked "MSX Toshiba T7775 8549EA1 MSX-ENGINE").
Source
[edit | edit source]
MSX Resource Center wiki, file page https://www.msx.org/wiki/File:Mpc200c_PCB_bottom.png, uploaded by Rderooy on 22 September 2016 ("Sanyo MPC-200 PCB - Toshiba T7775"). Retrieved 2026-10-21 and converted to JPEG.
Author
[edit | edit source]
Photograph uploaded to the MSX Resource Center wiki by Rderooy; the original photographer is not named there.
Licence
[edit | edit source]
No licence is stated on the source page; copyright remains with the photographer. Hosted for repair reference, with the source cited.
