File:Sanyo MPC-25FD power supply board.jpg
Summary
[edit | edit source]
The power supply board of a Sanyo MPC-25 series computer (board marked UF0673), cropped from File:Sanyo MPC-25FD main board.jpg. From the top: the mains input, a 6 W 2.2 Ω wirewound resistor, a heatsinked part, reservoir capacitor C005 (sleeve marked +85 °C), small electrolytics C007, C008, C011 and C012, a TDK transformer marked AE0081, two opto-couplers beside C020 and IC052, and at the bottom the secondary side with C050, C055, C056, a 100 µH choke and two more heatsinks.
Source
[edit | edit source]
Cropped from the MSX Resource Center wiki file https://www.msx.org/wiki/File:Mpc25f.jpg (uploaded by Mars2000you on 12 January 2016). Retrieved 2026-10-21.
Author
[edit | edit source]
Photograph uploaded to the MSX Resource Center wiki by Mars2000you; the original photographer is not named there.
Licence
[edit | edit source]
No licence is stated on the source page; copyright remains with the photographer. Hosted for repair reference, with the source cited.
