File:Sega Dreamcast controller port board KATANA SUB BD 2 KAI.jpg
Size of this preview: 800 × 229 pixels. Other resolution: 2,184 × 624 pixels.
Original file (2,184 × 624 pixels, file size: 334 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
Crop of the photograph above showing the Dreamcast controller-port board, marked "KATANA SUB BD 2 KAI", 171-8061A and 839-1169, in place in the console. Visible: the four controller ports CN1A, CN1B, CN2A and CN2B, the clock cell BT1, R1, LED1, the 20-way connector CN3, the 47 µF capacitor CE1, F1, and the three-way fan connector CN4 with its orange, blue and red leads.
Source
[edit | edit source]
Cropped from File:Sega-Dreamcast-Internals.jpg on Wikimedia Commons (retrieved 2026-10-25)
Author
[edit | edit source]
Evan-Amos
Licence
[edit | edit source]
Public domain. The author, Evan-Amos, released the photograph into the public domain, as recorded on Wikimedia Commons.
