File:Sharp PC-1360 main board capacitors (service manual).png
Size of this preview: 800 × 325 pixels. Other resolution: 1,300 × 528 pixels.
Original file (1,300 × 528 pixels, file size: 148 KB, MIME type: image/png)
Summary
[edit | edit source].png&veaction=edit§ion=1){kind=link}
.png&action=edit§ion=1){kind=link}
Part of the "Parts and signals position" drawing in Sharp's PC-1360 service manual: the 3.3 µF capacitor at the top left, three 1 µF capacitors in a row with arrows showing their fitting direction, the 30 kΩ and 10 kΩ divider resistors and the 20 kΩ contrast control. Rendered at 300 dpi from the scan and cropped.
Source
[edit | edit source].png&veaction=edit§ion=2){kind=link}
.png&action=edit§ion=2){kind=link}
File:Sharp PC-1360 Service Manual.pdf, PDF page 12. The scan came from Sharp Pocket Computers (sharppocketcomputers.com), retrieved 2026-10-21.
Author
[edit | edit source].png&veaction=edit§ion=3){kind=link}
.png&action=edit§ion=3){kind=link}
Sharp Corporation.
Licence
[edit | edit source].png&veaction=edit§ion=4){kind=link}
.png&action=edit§ion=4){kind=link}
Copyright Sharp Corporation. Hosted for preservation and repair reference, with the source cited.
